- FRAME WETHEPEOPLE "BATTLESHIP" frame, 20.75" TT, 4130 full crmo, hydroformed gussets, with removable brake pivots & guides
- FORK WTP "BATTLESHIP" fork, post liquid heat-treated butted sanko tubing, 1pc cnc steerer, 15mm offset
- BARS ÉCLAT "STRANGLER" bar, 4pc, post liquid heat-treated 4130 crmo, 25.4mm clamping
- STEM ÉCLAT "DOMAIN" topload stem, cnc alloy, 48mm reach, 25.4mm clamping
- CRANKS WTP "LOGIC" tubular 3pc crank, 22mm, crmo, 160mm, 48 spline
- BB WTP "COMPACT" bb, 22mm, sealed
- PEDALS ÉCLAT "CENTRIC"
- SPROCKET ÉCLAT "ELEVATE" sprocket & nylon guard, 6061-T6 alloy, 25t
- FRONT HUB ÉCLAT "CORTEX OS" hub, fully sealed, 3/8"s female bolts, 36h, oversize bearings
- REAR HUB ÉCLAT "SHIFT" freecoaster hub, fully sealed, "Hybrid Sytem" convertible internals, 9t drive, 14mm hollow axle, 36h
- RIMS ÉCLAT "BONDI" rim, 38mm wide, flash welded, double wall, 36h
- SEAT ÉCLAT "BIOS" pivotal seat, fat padded
- TIRES ÉCLAT "DECODER" tires, 2.40", 100PSI, front & rear
- WEIGHT 12.67kg /27.94lbs
FRAME GEOMETRY
Top Tube Length: 20.75"
Chainstay Length: 12.7" - 13.2"
Head Tube Angle: 75.5º
Seat Tube Angle: 71º
Bottom Bracket Height: 11.7"
Standover Height: 9"
BAR GEOMETRY
Rise: 9.1"
Width: 29.7"
Backsweep: 11.5º
Upsweep: 2.5º
